Description
ستيبر موتور مع شريحة تحريك
Stepper Motor with Driver Board
بيانات المنتج
RioRand Stepper Motor 5V DC 4-Phase 5-Wire + ULN2003 Driver Board Product
المواصفات
Rated Voltage: DC5V 4-phase
Stepping angle: 5.625 x 1/64
DC Resistance: 200Ω±7% (25C)
Insulation Resistance: >10MΩ (500V)
Dielectric Strength: 600V AC / 1mA / 1s
Pull in Torque: >34.3mN.m(120Hz)
Detent Torque: >34.3mN.m
Temperature Rise: <40K(120Hz) ULN2003 Driver Board
Motor diameter: 1.1 inch
Wire length：9.05 inch
Single set Weight: 0.1 pounds
بيانات أضافية
